Wifi Router

Model

B935

Color

White

Dimension

170mm*155mm*25mm

Technical Standard

Compatible with WCDMA, FDD-LTE
802.11 b/g/n

WiFi Chipset

RTL8192(802.11b/g/n)

Flash

4GB + 2GB

WiFi

2.4GHz, WIFI 2*2 MIMO，802.11 a/b/g/n

4G LTE Module

Qualcomm MDM9X07. CAT4 , DL/UL: 150/50Mbps

Frequency

LTE FDD:B1/B3/B5/B7/B8/B20
TD-LTE:B40
WCDMA:B1/8
TDSCDMA:B34/39
CDMA&EVDO BC0
GSM:850/900/1800/1900
Can switch module to cover more frequencies combination

MIMO

Support DL 2x2 MIMO

BB Chipset

Qualcomm MDM9207

RF Chipset

Qualcomm WTR2965

USIM/SIM

2FF SIM card
support SIM/USIM/UIM,standard 6 PIN SIM card interface,
support 3V SIM card and 1.8V SIM card;internal
push-push SIM slot

LED

Power Indication LED，WAN Signal Strength， WiFi/WPS Indication LED， WAN/LAN Status LED，Internet Status LED

USB

USB 2.0

Antenna

Internal Antenna only

Button

POWER, Reset, WPS

Ethernet

1WAN+3LAN, 10BaseT/100Base/1000Base automatic adaptive port

RJ11

RJ11 X 2

Reset

Pinhole

ESD

ESD Protection circuit；Contact±8KV、Air±10KV

Battery

Not Support

SW Update

TR069 & Local Update

WIFI Mode

AP mode only, AP+STA is Optional

WIFI Security

OPEN & WPA-PSK& WPA2-PSK & WPA-PSK/WPA2-PSK;

SMS & Phonebook

Not Support by default, can be customized

USB Function

Default no USB port, can be customized

VOICE

VoLTE & CS Domain voice & VOIP

AGPS

AGPS, no separate GPS chipset.
No information need to be displayed

IPv4

Supported

IPV6

Supported

Firewall

Mac/IP address filter, Port forwarding, WiFi Black/Whilte list

Data Statistics

Support

VPN Pass Through

PP2P/L2TP/IPSec

SIM Lock

Supported

WAN Fallback to ETH

Manually

HTTP

Supported

Environment

Operating Temperature: Normal:-10°C to +65°C;
Storage Temperature: -20° C to +85° C
Humidity: 5%~ 95%

Package

1pcs x 4G CPE

2pcs x External antenna

1pcs x AC adapter

1pcs x Ethernet Cable
